KTY20001-1R Clutch Kit Xtreme Performance Race Sprung Ceramic 900Kg (125%) 600Nm

Xtreme Performance - Extra Heavy Duty Sprung Ceramic/-1RRecommended for: Motorsport Applications

-1R kits feature a sprung ceramic friction disc, but with even greater clamping force pressure plate for higher torque capacity. These kits are designed specifically for motorsport applications such as circuit, rally, drifting and drag racing.

Specifications:

• Torque capacity 600Nm
• Clamp load 900Kg 125% Increased over standard
• Sprung Ceramic Friction Disc
• Extra Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

Xtreme PerformanceAt Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

What's in the Box?

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Tech. Info:

Reference: KTY20001-1R

Weight: 5.32

Note:

Clutch Disc Diameter (mm): 200
Clutch Disc Spline Count: 21
Clutch Disc Spline Diameter (mm): 23.8
Torque (Nm): 600
Flywheel Step: +.5mm/.020""
Design: Single Plate
Stage: Stage 2R
Clamp Load: 900Kg (125% inc.)
Recommended for: Race Vehicles - Stage 2R
Ring Gear Tooth count:
Additional information:

Single Plate

Suitable for:

- Toyota/Corolla/1.3 (AE80)/1985.09-1989.05/2A 1295 Petrol 48 kW 65 BHP (1985.09 - 1989.05)
Toyota/Corolla/1.3 (AE80)/1983.06-1984.10/2A-L 1295 Petrol 51 kW 69 BHP (1983.06 - 1984.10)
Toyota/Corolla/1.3 12V (EE100_)/1992.07-1997.04/2E 1296 Petrol 53 kW 72 BHP (1992.07 - 1997.04)
Toyota/Starlet/1.3 (EP90)/1996.11-1999.07/2E 1296 Petrol 53 kW 72 BHP (1996.11 - 1999.07)
Toyota/Corolla/1.3 i (EE90)/1989.08-1992.04/2E, 2E-E 1296 Petrol 55 kW 75 BHP (1989.08 - 1992.04)
Toyota/Corolla/1.6 (AE92)/1987.05-1992.11/4A-F 1587 Petrol 66 kW 90 BHP (1987.05 - 1992.11)
Holden/H Series/1.6/1989.08-1991.09/4A-FC 1587 Petrol 70 kW 95 BHP (1989.08 - 1991.09)
Toyota/Corolla/1.6 i (AE94)/1992.11-1995.10/4A-FE 1587 Petrol 75 kW 102 BHP (1992.11 - 1995.10)
Toyota/Corolla/1.6 (AE92)/1987.05-1992.05/4A-FE 1587 Petrol 76 kW 103 BHP (1987.05 - 1992.05)
Toyota/Corolla/1.6 GT (AE101)/1991.06-1997.08/4A-FE 1587 Petrol 85 kW 116 BHP (1991.06 - 1997.08)
Toyota/Corolla/1.6 i 20V (AE92)/1987.05-1991.06/4A-GE (20V) 1587 Petrol 102 kW 139 BHP (1987.05 - 1991.06)
Toyota/Corolla/1.6 GTI (AE92_)/1987.07-1993.06/4A-GE 1587 Petrol 92 kW 125 BHP (1987.07 - 1993.06)
Toyota/Corolla/1.6 (AE82)/1985.05-1987.04/4A-GEC, 4A-GELC 1587 Petrol 85 kW 116 BHP (1985.05 - 1987.04)
Toyota/Corolla/1.6 GT 16V (AE82_)/1985.08-1987.08/4A-GEL 1587 Petrol 89 kW 121 BHP (1985.08 - 1987.08)
Toyota/Celica/1.6 GT 16V (AT160_)/1986.04-1989.08/4A-GEL 1587 Petrol 91 kW 124 BHP (1986.04 - 1989.08)
Toyota/Corolla/1.6 (AE82)/1985.08-1987.08/4A-LC 1587 Petrol 53 kW 72 BHP (1985.08 - 1987.08)
Toyota/Corolla/1.6 (AE82_)/1985.12-1988.05/4A-LC 1587 Petrol 54 kW 73 BHP (1985.12 - 1988.05)
Toyota/Corolla/1.6 (AE82)/1985.04-1989.06/4A-LC 1587 Petrol 58 kW 79 BHP (1985.04 - 1989.06)
Toyota/Corolla/1.3 XLI (EE101_)/1995.08-1997.04/4E-FE 1332 Petrol 55 kW 75 BHP (1995.08 - 1997.04)
Toyota/Starlet/1.3 (EP91_)/1996.01-1999.07/4E-FE 1332 Petrol 55 kW 75 BHP (1996.01 - 1999.07)
Toyota/Corolla/1.4 (EE111_)/1997.04-2000.02/4E-FE 1332 Petrol 63 kW 86 BHP (1997.04 - 2000.02)
Toyota/Corolla/1.3 XLI (EE101_)/1992.07-1997.04/4E-FE 1332 Petrol 65 kW 88 BHP (1992.07 - 1997.04)
Toyota/Starlet/1.3 (EP82)/1989.12-1996.03/4E-FE 1332 Petrol 74 kW 100 BHP (1989.12 - 1996.03)
Toyota/Paseo/1.5 (EL54_)/1995.11-1999.12/5E-FE 1496 Petrol 69 kW 94 BHP (1995.11 - 1999.12)
Toyota/Paseo/1.5 (EL54_)/1995.08-1999.06/5E-FE 1497 Petrol 66 kW 90 BHP (1995.08 - 1999.06)
Toyota/Paseo/1.5 (EL44)/1990.06-1995.08/5E-FE 1497 Petrol 74 kW 101 BHP (1990.06 - 1995.08)
Toyota/Corsa/1.5 (EL43_)/1990.09-1994.09/5E-FE 1497 Petrol 75 kW 102 BHP (1990.09 - 1994.09)
Toyota/Corsa/1.5 (EL43_)/1990.10-1994.09/5E-FE 1497 Petrol 78 kW 105 BHP (1990.10 - 1994.09)
Toyota/Sera/1.5 (EXY10_)/1990.03-1995.11/5E-FHE 1496 Petrol 81 kW 110 BHP (1990.03 - 1995.11)
Toyota/Corsa/1.5 (EL43)/1990.09-1994.09/5E-FHE 1497 Petrol 85 kW 116 BHP (1990.09 - 1994.09)
Toyota/Corolla/1.4 (AE90)/1989.07-1992.11/6A-FC 1397 Petrol 60 kW 82 BHP (1989.07 - 1992.11)
Holden/H Series/1.4/1989.08-1991.09/6A-FC 1397 Petrol 60 kW 82 BHP (1989.08 - 1991.09) ,
